MA Gearbox Ball Bearing with Circlip Groove AB40361S01 25x52x15mm

SNR/NTN AB40361S01 Ball Bearing with Circlip Groove – Gearbox

The SNR AB40361S01 (also supplied as NTN SX05A87NCS30PX1) is a deep groove ball bearing with a circlip groove, designed for gearbox applications in MA 5-speed transmissions. The circlip groove allows secure axial location within the gearbox housing.

Inside Diameter: 25mm

Outside Diameter: 52mm

Width: 15mm

EAN: 3413520240851

Part Numbers: AB40361S01 (SNR), SX05A87NCS30PX1 (NTN)

Fits Transmission: MA (5 Speed)

Will I receive SNR or NTN brand?

Either SNR (AB40361S01) or NTN (SX05A87NCS30PX1) may be supplied — both are equivalent OEM-quality bearings for this application.

What is a circlip groove bearing?

A circlip groove (snap ring groove) on the outer ring allows the bearing to be retained axially in the housing using a snap ring, preventing axial movement without additional components.

Which gearbox uses this bearing?

This bearing is used in the MA 5-speed gearbox. If unsure, send your UK registration or VIN to confirm compatibility.

Is this a sealed or open bearing?

This is a standard gearbox bearing — open type, allowing gearbox oil lubrication.

What are the exact dimensions?

Bore 25mm, outer diameter 52mm, width 15mm.

Why Choose Eco Torque?

As specialists in gearbox rebuilds and repairs, Eco Torque takes pride in offering genuine gearbox parts, high-quality aftermarket alternatives and competitive pricing.

Need Help Finding the Right Part?

If you are unsure whether this part is compatible with your vehicle, send us your UK registration number or VIN and we will help you find the correct part.

Reference Number: ET2110
