Introduction
Below is a quick reference guide for those of you who may not be familiar with the terminology associated with VAG vehicles. If there's something missing that you'd like to see, leave a comment, and we'll add it to the blog!
VAG
Volkswagen Audi Group is the main company that 10 different car brands sit under including Audi, Seat, Skoda and VW.
ODIS
The ODIS VW Group Diagnostic Tool is an all-in-one powerhouse for key programming, ECU and control unit replacement, software updates, and accessing essential technical bulletins (TPI). It also grants full access to workshop manuals and wiring diagrams—basically everything but the coffee machine!
VAG Part Numbers
Since this section is quite large, we’ll keep it brief. For those who want a deep dive (or need help falling asleep), there are plenty of detailed guides available online.
VAG uses an efficient part numbering system where each component type is given a prefix code.
As shown in the image, all the components start with “02T”, identifying the main component. This is why transmissions are often referred to by codes like “0AM” or “02E” – these serve as easy reference points for gearbox identification.
Gearbox Codes & References
- DSG: The German abbreviation for Direktschaltgetriebe which translates to Direct Shift Gearbox. This term refers to all dual-clutch transmissions found in Audi, Seat, Skoda, VW vehicles.
- Common references, such as “DQ200” and “DL381”, often appear online when discussing DSG gearboxes.
- These codes can be broken down further to explain their specific meanings.
Gearbox Type
D - Direct Shift Gearbox (DSG)
M - Manual Gearbox
A - Automatic
V - Multitronic / CVT
Gearbox Orientation
Q - This is a transverse mounted gearbox which is a common set up for most front wheel drive vehicles.
L – This is a longitudinal gearbox and is mounted length-ways in the vehicle. Usually seen on larger transmissions for higher engine power applications.
Power Capability
The last set of numbers are the manufacturers recommended torque capacity in which the gearbox can work with. However, the vehicles they are fitted to often exceed this last number.
Get In Touch
Have we missed anything? - if so, just leave us a comment below.
For specific enquiries, please reach out to us directly using the contact details provided.
